Our range of rail computers is designed to EN50121-4:2006 standards for a diversity of railway applications. Powered by Intel’s Core-i processors, these rackmountable computers offer excellent performance, redundant power supplies and hot-swap storage with RAID support. This makes them ideal choice for a critical rail applications, from surface to underground installations, including trackside.
To learn more about our rack integration services, visit our rackmount computers main page.
Through expert component selection and extensive industry know-how, we offer a range of configurable 4U rackmount systems that are designed to EN50121-4:2006 rail standards.
Industrial-grade components, filtered air intakes and front I/O protection allow for flexible installation into various rail environments, including trackside.
Industry-leading performance with Intel® Core i technology. The RC-44 features options for a range of processors with on-board graphics, ensuring the perfect balance between performance and budget is achieved for your application.
High reliability, industrial-grade components designed for 24/7 operation combined with a robust construction optimises the service life of the RC-44.
The RC-44 features dual redundant power supplies offering high availability, 24/7 continuous operation for critical applications.
The RC-44 features hot-swappable drive bays for ease of access supporting either HDD or SSD. Additionally RAID support offers enhanced data integrity to keep critical information secure.
| CPU | Intel® Core-i 3/5/7 Processor |
| Memory | Up to 32GB RAM |
| Graphics | Intel® graphics |
| Expansion | 7 full height full length slots |
| LAN | 2 x Gigabit Intel® LAN |
| Storage | 3 x 3.5” Hot-swap HDD or SSD supporting RAID 0,1,5 |
| Video / Audio | VGA (DSub) / Display port |
| Operating System | Windows 10 / Windows Server 2012 / Linux |
| Power Supply | Redundant 1+1 500W hot-swap power supply |
| Input Voltage | 105-264VAC |
| Operating Temperature | 0c-60c |
| Dimensions | 427mm x 176mm x 570mm |
| DVD | SATA DVDRW |
